PA5SAN53602W
P = Builder / Brand Type
A = AC / OD Type
5 = 14.3 SEER2
S = Single-Stage / OD Design Type
A = Major Iteration
N = 208/230-1 / Voltage
5 = R-454B / Refrigerant
36 = 36,000 BTUH (3 Tons) / Nominal Capacity
0 = Standard / Feature
2 = Coil Optimization / Special Feature
W = Standard SW AC / Region
This unit has been designed utilizing non-ozone depleting, low global warming potential R-454B refrigerant.
Air conditioners with R-454B refrigerant provide a collection of features unmatched by any other family of equipment.
NOTE: Ratings are subject to change at any time. Always refer to the AHRI directory (www.ahridirectory.org) for the most up-to-date ratings information.
Features / Benefits
Efficiency
13.8 - 17.0 SEER2 / 11.2 – 14.5 EER2
Microchannel Technology refrigeration system
Indoor air quality accessories available
Comfort
System supports programmable or standard thermostat controls
Reliability
Non-ozone depleting, low global warming potential R-454B refrigerant
Scroll compressor
Internal pressure relief valve
Internal thermal overload
Filter drier
Durability
Protection Package:
Solid, durable sheet metal construction
Dense wire coil guard
Applications
Long–line – up to 250 feet (76.20 m) total equivalent length, up to 200 feet (60.96 m) condenser above evaporator, or up to 80 ft. (24.4 m) evaporator above condenser (See Long Line Guide for more information.)
Low ambient cooling (down to 0°F / -18°C ) with approved low ambient accessory kits.
Limited Warranty
5-year parts limited warranty (including compressor and coil)
10-year parts limited warranty (including compressor and coil) with timely registration*
– Equipment must be registered within 90 days of original installation, except in jurisdictions where warranty benefits cannot be conditioned on registration.
